KNX dimmer|10A KNX dimmer|LTX0410K|LTX0610K|LTX0810K|LTX1210K
Profile
● This dimming power amplifier utilizes trailing-edge phase dimming technology.
● It accepts KNX signal inputs and converts them into high power 0-230V dimming output.
● Compatible with incandescent lamps, dimmable LED lamps, and low voltage halogen lamps with electronic transformers.
● Each channel delivers up to 2000W of output power.
Features
● Wall-mounted installation with built-in air switch and easily replaceable channel cards
● Independent circuit breaker protection and bypass switching capability
● Touchscreen graphical interface for interactive dimming control
● Multi-stage temperature protection system
● Load short-circuit protection function
● Open-circuit and short-circuit detection with alarm for loads
● Power line fault alarm
● Transparent air switch cover to prevent accidental operation
Technical Parameters
Model No | LTX0810K | LTX0410K | LTX0610K | LTX1210K |
Brand | LAMMIN |
|
|
|
Input Signal | KNX signal |
|
|
|
Input Voltage | AC 380V |
|
|
|
Output Voltage | AC 0-230V |
|
|
|
Frequency Range | 50Hz |
|
|
|
Max Load Current | 10A/CH*8 | 10A/CH*4 | 10A/CH*6 | 10A/CH*12 |
Max Output | 2000W*8 | 2000W*4 | 2000W*6 | 2000W*12 |
Min Load | 25W |
|
|
|
Certification | CE |
|
|
|
Working Temp | -20℃~+50℃ |
|
|
|
Warranty | 3 years |
|
|
|
Size(L*W*H)MM | 505*350*135 | 280*235*130 | 280*340*130 | 580*350*135 |
Installation | Wall-mounted |
|
|
|
Customization |
|
Datasheet:
specification LTX0410K.pdf
specification LTX0610K.pdf
specification LTX0810K.pdf
specification LTX1210K.pdf
