DALI gateway|DALI-RS485 two-way gateway (100 address)|LD-BC100
Profile
●LD-BC100 is R485-DALI converter,bidirectional send command;
●Manual gateway address setting, up to 100 gateway addresses with DALI power supply.
Features
●Low voltage power supply (DC12V/DC24V)， more safety
●With manual gateway address setting, up to 100 gateway addresses (0-99)
●With receiving indicator (one flash/ one command)
●Small size, easy to install
Technical Parameters
Model No | LD-BC100 |
Brand | LAMMIN |
Input Signal | R485 signal |
Input Voltage | DC12V/DC24V |
Output Signal | DALI signal |
Gateway Address | 100*addresses(0-99) |
Certification | CE |
Working Temp | -20℃~+50℃ |
Warranty | 3 years |
Size(L*W*H)MM | 54*88*65 |
Installation | 35mm DIN rail |
Datasheet:
specification LD-BC100.pdf
